By definition, a thermocouple measures temperature at a single point in the form of what is called EMF, or electric current. Due to the small amount of EMF generated by a device, sensitive instruments are recommended for calculating the EMF generated by a circuit (millivolts).
They are active transducers because they convert energy. Despite their size, they do not require electricity. Basically, they measure thermocouple temperature as an EMF. Pairs of thermocouples are constructed by combining certain metals. As the circuit temperature increases, these metal combinations increase linearly in EMF.
Working Principle Of Thermocouples
If two different metal wires are connected in a thermoelectric circuit and one end is heated, direct current will flow. If this circuit is cut in the middle, the net open circuit voltage depends on the junction temperature and the composition of the two metals. By this, it means that when two metals are heated or cooled, they generate intermediate temperatures. The voltage output depends on the number of junctions created.
What is a Thermocouple Sensor?
Thermocouples have three effects, the aforementioned ‘Seebeck effect’, the ‘Thomson effect’, and the ‘Peltier effect’. Now the question is, what are these effects?
Seebeck Effect
Physicist Thomas Seebeck discovered in 1821 that the temperature of a junction in a circuit equals the current flowing through it. This is because two different metal thermocouple wires are connected across the junction. It is an electromagnetic field (EMF). As a result of this circuit, energy is generated which is known as the Seebeck effect, which is usually defined by additive voltages.
There is a relationship between the temperature difference between the junctions and the amount of EMF induced by the combination of metals. This is the basic working principle of a thermocouple.
Thomson Effect
A change in junction temperature results in a change in voltage as well. Electronic controllers can monitor this using their input circuits. The temperature difference between the junction and free end determines the output voltage. This is known as the Thompson effect.
When two dissimilar metals combine to form two junctions, a temperature gradient along the conductor in the circuit creates an electrical potential and an ice bath if used. Thomson effects predict relatively small EMFs that can be ignored when metals are carefully selected.
Peltier Effect
Wheatstone bridge circuits rely heavily on the Peltier effect for thermocouple operation. This effect is the exact opposite of the Seebeck effect. The potential difference between two conductors can be used to produce different temperatures.
To create two same-temperature junctions, two metals need to be joined together to form a thermocouple circuit. A temperature difference between two junctions in a circuit produces a Peltier EMF. A circuit’s total EMF can be calculated using what is called the junction temperature and also the resistance properties of the metals used in the circuit.
In a circuit, an unknown-temperature object is attached to one of the connections, creating a hot junction and a cold junction. Cold junctions and reference junctions are connection points where objects whose temperatures are known are connected. The thermocouple voltage or current can be measured directly with a voltmeter when the thermocouple circuit is connected to a voltmeter.
As a result, a reference temperature can also be obtained. Analog-to-digital converters (ADCs) and microcontrollers can easily read the signal generated by a thermocouple junction using ADC cards.
Working with Response Time
The time response constant is the time required for the sensor to reach 63.2% of a step change in temperature under a specified set of conditions. A constant temperature bath and five-time constants are needed for the sensor to approach a 100% change in value. For easier voltage reading, thermocouple tables can be used to record these temperature changes.
The fastest response is provided by exposed junction thermocouples. In addition, smaller probe sheath diameters can provide faster responses, but at a lower maximum temperature. It may be necessary to repeat the step if the probe sheath cannot handle the full temperature range of the thermocouple. See the LabVIEW program to learn more.
How To Choose A Thermocouple
Thermocouples come in many types. To help you decide which product to buy, most manufacturers offer selection guides. Technical support specialists are also available from reputable manufacturers. You will be guided through a series of questions and help select the right thermocouple for your application, so carry a lab handbook with you.
